详情介绍
低水泥系列浇注料
Low Cement Series Castable
【使用部位 Using Position】
加热炉、均热炉、退火炉及其它热处理炉的工作层;
熔铝炉、静置炉炉墙、顶、底;铝水包、流槽、感应电炉衬体;
高炉及其附属设备、连铸中间包、混铁炉、化铁炉炉衬浇注或预制;
化工设备如合成氨一段、二段转化炉衬里浇注;
各种高温窑炉烧嘴工作层;
工业锅炉衬体。
The working layer of heating furnace, soaking furnace, annealing furnace and other heat treatment furnace;
The wall, roof and bottom of aluminum melting furnace and holding furnace; aluminum-water ladle, launder and induction furnace liner;
High furnace and its accessory equipment, continuously cast tundish, metal mixer, iron-melting furnace liner casting or prefabricating;
Chemical equipment, such as liner casting of ammonia synthesis 1-phrase converter and 2-phrase converter;
Various high temperature burner working layer;
Industrial boiler liner
【理化指标Physiochemical Index】
型?号Model |
主要原料Main raw material |
化学成分% Chemical composition |
最高使用温度℃ Maximum service temperature |
耐火度℃Refractoriness |
体积密度g/cm3 Bulk density |
1400℃烧后线变化% Reheat linear change of 1400℃ |
烧后抗压强度MPa Crushing strength |
||
Al2O3 |
CaO |
110℃×24h |
1400℃×3h |
||||||
LC-L50 |
高 铝Alumina |
≥50 |
≤2.5 |
1400 |
1680 |
2.35 |
±0.5 |
≥25 |
≥50 |
LC-L60 |
高 铝Alumina |
≥60 |
≤2.5 |
1450 |
1700 |
2.45 |
±0.5 |
≥25 |
≥50 |
LC-L65 |
高 铝Alumina |
≥65 |
≤2.5 |
1500 |
1700 |
2.50 |
±0.5 |
≥27 |
≥55 |
LC-L70 |
高 铝Alumina |
≥70 |
≤2.5 |
1550 |
1750 |
2.60 |
±0.5 |
≥30 |
≥60 |
LC-M52 |
莫来石Mullite |
≥52 |
≤2.5 |
1400 |
1650 |
2.30 |
±0.5 |
≥25 |
≥50 |
LC-M62 |
莫来石Mullite |
≥62 |
≤2.5 |
1450 |
1680 |
2.30 |
±0.5 |
≥30 |
≥55 |
LC-M68 |
莫来石Mullite |
≥68 |
≤2.5 |
1500 |
1700 |
2.40 |
±0.5 |
≥30 |
≥60 |
LC-A85 |
刚 玉Alumdum |
≥85 |
≤2.5 |
1680 |
1780 |
2.85 |
±0.5 |
≥40 |
≥70 |
LC-A90 |
刚 玉Alumdum |
≥90 |
≤2.5 |
1700 |
1800 |
3.00 |
±0.5 |
≥40 |
≥85 |
有关技术参数可根据具体使用环境及要求另行约定
Relevant technical parameter can be otherwise appointed according to special environment and requirement of using
